One 5-inch hole, 9.5″ × 9.5″ × 14″ outside. If the barrel clears 5 inches (127mm), it drops in. This is not a case cut for one lens set — it is built to a hole size — common cinema primes like Cooke S4/i and S7/i, Master Prime, Summilux-C and CN-R share this one, so it still fits when the glass in the fleet changes.
Pre-made in black and held in stock. A custom-cut case stays dedicated to that lens set; this one stays useful as the fleet changes, which is why it holds its value on the rental shelf. Ordered before the carrier cut-off, it goes out the same day rather than in three weeks.
Specifications
| Hole count | 1 |
| Hole size | 5″ (127mm) |
| Layout | Single lens |
| Exterior dimensions | 9.5″ W × 9.5″ D × 14″ H |
| Interior height | 14″ — clears any prime up to 11-1/2″ long |
| Foam spacing | 2″ to the wall, 1-1/2″ between lenses |
| Construction | ATA 300 hand-built flight case · 0.25″ panels · CNC-cut foam |
| Fits | Common cinema primes. Cooke S4/i and S7/i, Master Prime, Summilux-C, CN-R. |
| Lead time | In stock in black — ships the same day |
What is in the box
- The case, with 1 vertical hole at 5 inches
- CNC-cut foam insert with finger grips at 45 degrees on every hole
- A 1-3/4″ hard riser per hole that cups the PL mount
- Soft foam levelling circles to bring a mixed set up to the lid
- A 1-5/8″ desiccant holder (desiccant not included)
- Full-foam ELE lid, no holes
Fit & shipping FAQ
Will my set fit?
If every barrel clears 5 inches (127mm) and no lens is longer than 11-1/2 inches, yes. Common cinema primes like Cooke S4/i and S7/i, Master Prime, Summilux-C and CN-R already live in this hole — look yours up in the fit checker.
What if one lens is longer than the rest?
The interior is 14 inches tall at every hole, so a mixed set is fine. Soft foam circles under the shorter lenses bring them up until the lid foam makes contact on all of them.
What comes in the box?
The case, the CNC-cut foam insert, a full-foam lid, a hard riser for every hole, a bag of soft levelling circles, and the desiccant holder. Desiccant itself is not included.
Can you cut it to my exact set instead?
Yes. That is a made-to-order build — 14 to 21 business days, and the quote comes with a dimensioned drawing before anything is cut. Start here.
Does it really ship the same day?
On stock configurations in black, ordered before the carrier cut-off, yes. That is the whole point of pre-making these instead of cutting each one to order.
Glass that needs a bigger hole than 5 inches? ARRI Signature, Cooke S8/i, Cooke Anamorphic/i and most rehoused vintage are cut to fit — 14 to 21 business days with a dimensioned drawing in the quote. Request one or call the shop at 818-767-3030.
Other hole sizes in this line: all Universal Vertical cases.
Find more cases for your gear: look up your lens series.
Specifications
- 4900-V1-500
- Availability:
- Ships within 24 hours
- Weight:
- 15.00 LBS
- Shipping:
- Calculated at Checkout
- Exterior Dimensions:
- 9.5 x 9.5 x 14 in
- Made In:
- North Hollywood, California, USA
- Lead Time:
- Ships within 24 hours
- Hole Size:
- 5 in (127mm)
- Hole Count:
- 1
- Interior Height:
- 14 in
- Fits Lens Series:
- Common cinema primes. Cooke S4/i and S7/i, Master Prime, Summilux-C, CN-R.
- Case Construction:
- ATA 300, 0.25 in panels
- Model:
- UV-1 · 5″
- Stock Status:
- In Stock
- Fits Statement:
- Any lens whose barrel clears the hole size shown above and is no longer than 11-1/2 inches. Confirm your series in the fit checker.
Will this fit my setup?
Tell us what you’re protecting and everything that travels with it. We check it against this build’s foam layout and reply with either a confirmation or the change we’d make. No obligation, and it goes to the people who cut the foam.
Got it — we’re checking your package.
We have your configuration and the exact build you were looking at. You’ll hear back with a fit confirmation or the modification we’d recommend.
My setup is different
Different body, extra accessories, an accessory that has to stay mounted, or dimensions that don’t exist yet. We modify an existing design or engineer a new one.
I need several
Repeatable foam layouts, consistent hardware, replacement foam and reorders against the same drawing. Standard practice for rental houses and studio fleets.
