A mid-size shell, supplied bare. The Pelican 1610 gives you 21.78" x 16.69" x 10.62" to work with, 2.23 ft³, and weighs 19.5 lbs before anything goes in. Protector-series shell — watertight O-ring, automatic purge valve, lifetime guarantee. Send a kit list and we will come back with a foam layout for it.
Make it yours — Innerspace your Pelican 1610
Buy it off the shelf, or have our team build CNC-cut custom foam, padded dividers, and laser-engraved panels fit to your exact gear. Ordering more than one? We standardize configurations and re-order at volume pricing so every case across your team or fleet matches.
Request a quote →Key Features
- Polypropylene construction
- Watertight, crushproof, and dustproof
- Strong polyurethane wheels with stainless steel bearings
- Ships empty — Pick N Pluck™ foam sets sold separately
- Open-cell core with solid-wall design — strong, lightweight
- Retractable extension trolley handle
Specifications
Body: Polypropylene · Latch: ABS · O-Ring: Polymer · Hardware: Stainless Steel · Purge Vent: 3-Micron Hydrophobic
Ships empty — ready for your custom foam or dividers.
Complete your kit
Case Dimensions
- Interior
- 21.78 × 16.69 × 10.62 in
- Exterior
- 24.83 × 19.69 × 11.88 in
- Shipping weight
- 19.50 LBS
Interior is the usable space inside the case. Measure your gear at its widest points and allow for foam.
Specifications
- SKU:
- 1610-021-110
- UPC:
- 019428086930
- Availability:
- Ships in 1-2 Business Days
- Weight:
- 19.50 LBS
- Shipping:
- $50.00 (Fixed Shipping Cost)
- Gear:
- Accessory / Other
- Case Shell:
- Pelican 1610
- Case Construction:
- Injection Molded
- Protection Rating:
- IP67 Waterproof
- Certifications:
- IP67 / Def Stan 81-41
- Operating Temperature:
- -40°F to 190°F
- Wheels / Handle:
- Yes
- Interior Dimensions:
- 21.78 × 16.69 × 10.62 in
- Exterior Dimensions:
- 24.83 × 19.69 × 11.88 in
Will this fit my setup?
Tell us what you’re protecting and everything that travels with it. We check it against this build’s foam layout and reply with either a confirmation or the change we’d make. No obligation, and it goes to the people who cut the foam.
Got it — we’re checking your package.
We have your configuration and the exact build you were looking at. You’ll hear back with a fit confirmation or the modification we’d recommend.
My setup is different
Different body, extra accessories, an accessory that has to stay mounted, or dimensions that don’t exist yet. We modify an existing design or engineer a new one.
I need several
Repeatable foam layouts, consistent hardware, replacement foam and reorders against the same drawing. Standard practice for rental houses and studio fleets.
